Linear light connector

The side covering plug is a connector that connects the cladding keel and the side keel, and is also an accessory used to adjust the unevenness of the wall. The side covering plug is required to connect the cladding keel to the side keel.

The leveling top and bottom parts are composed of three parts: the leveling top part, the leveling bottom part and the smooth screws. When the ceiling height is 110~180mm or 200~300mm, the leveling top and bottom parts can be used as the vertical support of the ceiling. It can be used to adjust the uneven ceiling.

The top cover connector is a connector that connects the vertical covering keel and the top keel. When the vertical support adopts the vertical covering keel and the top keel adopts the covering keel, the top cover connector is required to connect them. It is used to adjust the uneven top.

The swivel connector can rotate 360 ​​degrees at will, which solves the problem that the keel cannot fit well when making special-shaped ceilings. When the vertical support of the ceiling uses a covering keel, the swivel connector is used to connect it with the horizontal covering keel.

The light trough support is used to support the light strip in the light trough. When making a ceiling with a light trough, use the light trough support to support the light strip so that the light is evenly distributed.

The fixing piece is used to connect two covering keels. When two covering keels are placed vertically, the fixing piece is used to connect the two keels.

The leveling assembly consists of three parts: the leveling base, the screw rod, and the leveling clamp. It is mainly used as the vertical support of the ceiling. Use your fingers to squeeze the holes on the spring sheet in the same direction so that they are parallel to the holes on the base. Slide the screw rod through the hole to adjust the uneven ceiling.
